★ LF-PV Series Pure Sine Wave Inverter is a combination of a 48-volt inverter, AC charger, and Auto-transfer switch into one complete system (without MPPT).
★ The split-phase inverter requires 240VAC input and can provide 120VAC or 240VAC output power for all kinds of appliances, and it can output 50 or 60Hz via the SW4.
★ AC/Battery Priority: Our inverter is designed with AC priority by default, you can choose the battery priority by SW5 switch.
★ Features: Smart Remote Control, Automatic Generator Starting (AGS), Suitable for different kinds of batteries.
★ Application: for all kinds of loads: refrigerators, freezers, microwaves, dryers, air conditioners, pumps, and all the big home and business applications.
Main Specification
Model
LFPV18K48V240VSP
Continuous Output Power
18.0KW
Surge Rating(20s)
54.0KW
Output Waveform
Pure Sine Wave
AC Output Voltage
120V and 240V
AC Input Voltage
240V( not suitable for AC 120V input )
DC Battery Voltage
48Vdc
AC Battery charger
95±5Amp
Output Frequency
50Hz /60Hz
Typical transfer Time
10ms(Max)
DC Input
Nominal Input Voltage
48.0Vdc
Minimum Start Voltage
40.0Vdc / 42.0Vdc
Low Battery Alarm
42.0Vdc / 44.0Vdc
Low Battery Trip
40.0Vdc / 42.0Vdc
High Voltage Alarm
64.0Vdc
Low Battery voltage recover
62.0Vdc
Power Saver on Idle Consumption
50W
Power Saver off Idle Power
270W
Charger
Output Voltage
Depends on battery type
Battery Initial Voltage for Start Up
40-62.8V
Over Charge Protection Shutdown
62.8V
Charger Breaker
100A
Input Voltage Waveform
Sine wave (Grid or Generator)
AC input range
184-253Vac/140-270Vac
Nominal Input Frequency
50Hz or 60Hz (Auto detect)
Packaging
18000W 48V Split Phase Pure Sine Wave Power Inverter
English Manual
Remote Control
BTS Cable
Unit Weight
197 LB
Unit Size
28.7 x 16.5 x 8.7 inch
Shipping Weight
232 LB
Shipping Size
34.25 x 21.3 x 17.3 inch
